The principle of the system is to receive the drone beacon signal and decode the information in the radio message. By utilizing UAV detection technology, various information can be extracted, including but not limited to the UAV model (SN code), geographical location of the remote control, return point location, current UAV position, flight speed, flight altitude, and additional data. The system includes APIs for forwarding inspection data to other systems, facilitating connections between individual systems.
Detection range | 1-3KM (The range depends on the antenna installed on the device) |
Detection time | Under normal circumstances ≤30 seconds (the detection time may change as the distance of the drone increases) |
Overall power consumption | 50W |
Temperature resistance | - 30℃～50℃ |
weight | 2KG |
Drone models can be detected | Phantom 4 Pro V2.0 Inspire series/Mavic series Avata series/Matrice series, DJI Mini series/AIR series, DJI FPVseries/MG-1P/T16/T20 |
dimension | 280mm * 150mm * 50mm |
The single device can display the position of the flying hand in real time
It can locate the flying position of the drone
The unique serial number of the UAV can be identified
Multi-unit networking
Second-level deployment, ready to boot
Portable design, small size, carry around
