Vehicle-mounted Drone Detection and Countermeasures Equipment EXA-CZ-2023

Vehicle-mounted Drone Detection and Countermeasures Equipment EXA-CZ-2023

The system should be able to sense early warning information in the surrounding area as the vehicle moves,Real-time display of target orientation, and real-time status monitoring, and can pass.The control terminal intercepts and handles the UAV target. This system adopts wireless. The electro-intelligent spectrum is a means of detection, which is equivalent to the attack means of broadband suppression technology.Combined as a whole, the formation of a regional net cover type protection means, constituting a comprehensive.Drone defense system. To achieve the defense target as the center, establish the radius not In the area of clearance less than 2 km, the UAV signal waves are realized.Time monitoring; Within the perimeter, drone signals will be picked up instantaneously,In a very short period of time, the defense system automatically starts the defense system to achieve zero.Automatic defense of man-machine targets.

Online Consultation

Technical Specification of Vehicle-mounted Drone Detection and Countermeasures Equipment EXA-CZ-2023

Device type:

Spectrum detection and counter

Radio frequency:

From 70MHz to 6GHz

Real-time detection bandwidth:

160MHz

Horizontal detection Angle range:

0°~360°

Detection distance:

1-4KM

Counter range:

> 1 km (100 m high)

Countermeasure frequency: Default value

Default value Default value Default value


900-930MHz 40±1dBm

1559-1610MHz 40±1dBm

2400-2485MHz 40±1dBm

5725-5850MHz 43±1dBm

GPS automatic positioning:

Device direction sensing of the north pointer:

Set the white list:

WIFI drone recognition:

Identify industrial jump drones

Autonomously identify unrecorded drones:

Working temperature:

-20°~60°

Storage temperature:

-40°~70°

Maximum power consumption:

<280W(sending)

Size:

682mm*538mm*345mm

Weight:

25Kg

Protection level:

IP65


Features of Vehicle-mounted Drone Detection and Countermeasures Equipment EXA-CZ-2023

  • Detection and countermeasure integrated, smaller, lighter

  • Autonomously learning and identifying unrecorded drones

  • Identify the model and locate its azimuth and distance

  • Suitable for industrial, consumer and WIFI

  • Full band detection, from 70MHz to 6GHz

  • Can handle more than 10 targets simultaneously

  • Unattended and manual, two modes

  • 160MHz real-time processing bandwidth

  • The detection distance can reach 1km-3km

  • Special frequency hopping signal recognition technology

  • Intelligent gain and reference level patented design

  • Aerial UAV signal feature recognition

  • Whitelist function
